• Year
  • 1952
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 137949

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Wave bands
  • Broadcast, Long Wave and 2 x Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 19 cm = 7.5 inch
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Fidex - LiRaR, Les Ingéneurs Radio
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 610 x 340 x 310 mm / 24 x 13.4 x 12.2 inch
  • Notes
  • 4 gammes d'ondes dont 1 bande étalée (BE) sur OC.

    Ce modèle existe en version 25 périodes et pour l'exportation.

  • Source of data
  • -- Original prospect or advert
  • Author
  • Model page created by Eddy Rischmann. See "Data change" for further contributors.
