- Country
- France
- Manufacturer / Brand
- LMT (L.M.T.), Le Matériel Téléphonique, Radiojour; Paris, Boulogne-Billancourt
- Year
- 1933/1934
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 254458
Publicité 1934
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 134 kHz; Reflex
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 30 - LMT L.M.T., Le Matériel
- Shape
- Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
- Dimensions (WHD)
- 365 x 485 x 240 mm / 14.4 x 19.1 x 9.4 inch
- Notes
-
Prise spécial pour adaptateur ondes courtes modèle 10. Ébénisterie forme "pendule".
- Net weight (2.2 lb = 1 kg)
- 11 kg / 24 lb 3.7 oz (24.229 lb)
- Price in first year of sale
- 1,350.00 FRF
- Mentioned in
- -- Original prospect or advert (Publicité 1933, 1934)
- Literature/Schematics (1)
- Le grand livre de la TSF (Doctsf Ref 20928)
- Literature/Schematics (2)
- -- Original prospect or advert (Catalogue 1933 environ)
- Literature/Schematics (3)
- Dépliant ARC-Radio, Nouveautés 1934
