FR Series Professional Power Amplifier M800

FR Series Professional Power Amplifier M800; LOUD Technologies, (ID = 1693083) Ampl/Mixer FR Series Professional Power Amplifier M800; LOUD Technologies, (ID = 1693084) Ampl/Mixer
FR Series Professional Power Amplifier M800; LOUD Technologies, (ID = 1693085) Ampl/Mixer FR Series Professional Power Amplifier M800; LOUD Technologies, (ID = 1693086) Ampl/Mixer
FR Series Professional Power Amplifier M800; LOUD Technologies, (ID = 1693087) Ampl/Mixer FR Series Professional Power Amplifier M800; LOUD Technologies, (ID = 1693088) Ampl/Mixer
FR Series Professional Power Amplifier M800; LOUD Technologies, (ID = 1693089) Ampl/Mixer FR Series Professional Power Amplifier M800; LOUD Technologies, (ID = 1693090) Ampl/Mixer
FR Series Professional Power Amplifier M800; LOUD Technologies, (ID = 1693091) Ampl/Mixer FR Series Professional Power Amplifier M800; LOUD Technologies, (ID = 1693092) Ampl/Mixer
Use red slider bar for more.
FR Series Professional Power Amplifier M800; LOUD Technologies, (ID = 1693083) Ampl/Mixer
LOUD Technologies,: FR Series Professional Power Amplifier M800 [Ampl/Mixer] ID = 1693083 750x500
Select picture or schematic to display from thumbnails on the right and click for download.
For model FR Series Professional Power Amplifier M800, LOUD Technologies, Mackie Designs; Woodinville (WA)

Country:  United States of America (USA)
Manufacturer / Brand:  LOUD Technologies, Mackie Designs; Woodinville (WA)
Year: 1999 ? Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 50-60 cycles, 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 800 W (undistorted)
from Radiomuseum.org Model: FR Series Professional Power Amplifier M800 - LOUD Technologies, Mackie
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 483 x 89 x 387 mm / 19 x 3.5 x 15.2 inch
Notes

800 watts @ 4 ohms bridged

550 watts @ 8 ohms bridged

400 + 400 watts @ 2 ohms stereo

275 + 275 watts @ 4 ohms stereo

175 + 175 watts @ 8 ohms stereo

Net weight (2.2 lb = 1 kg) 12.7 kg / 27 lb 15.6 oz (27.974 lb)

Model page created by Bartosz Szwed. See "Data change" for further contributors.
