• Country
• Taiwan (Republic of China)

• Manufacturer / Brand
• Lutron; Taipei

• Year
• 1985 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 347182

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 2

• Semiconductors
• 2N5246 9014 or. BC547 ICL7116CPL CD4070 TL061 TL061 1N4001 1N4148 KB165 unknown_Display

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / PP3: 1 x 9 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Digital Clamp Meter DM-6025 /C /F - Lutron; Taipei

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Notes

• Lutron Electronic Enterprise Co., Ltd., Digital Clamp Meter DM-6025

  3-½ digit 0.5" LCD display

  /C: C Degree Temp.
  /F:  F Degree Temp.

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
