Stereo Graphic Equalizer G-111

Stereo Graphic Equalizer G-111; Luxman, Lux Corp.; (ID = 1871369) Ampl/Mixer

Stereo Graphic Equalizer G-111; Luxman, Lux Corp.; (ID = 1871371) Ampl/Mixer
Stereo Graphic Equalizer G-111; Luxman, Lux Corp.; (ID = 1871342) Ampl/Mixer Stereo Graphic Equalizer G-111; Luxman, Lux Corp.; (ID = 1871345) Ampl/Mixer
Stereo Graphic Equalizer G-111; Luxman, Lux Corp.; (ID = 1871349) Ampl/Mixer Stereo Graphic Equalizer G-111; Luxman, Lux Corp.; (ID = 1871352) Ampl/Mixer
Use red slider bar for more.
Stereo Graphic Equalizer G-111; Luxman, Lux Corp.; (ID = 1871342) Ampl/Mixer
Luxman, Lux Corp.;: Stereo Graphic Equalizer G-111 [Ampl/Mixer] ID = 1871342 1400x1763
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo Graphic Equalizer G-111, Luxman, Lux Corp.; Kinsuido of Osaka:
Owners Manual

Country:  Japan
Manufacturer / Brand:  Luxman, Lux Corp.; Kinsuido of Osaka
Year: 1988–1990 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 230 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo Graphic Equalizer G-111 - Luxman, Lux Corp.; Kinsuido of
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 438 x 76 x 234 mm / 17.2 x 3 x 9.2 inch
Notes

Luxman Stereo Graphic Equalizer Model G-111.
Frequency Bands: 31, 62, 125, 250, 500, 1000, 2000, 4000, 8000, 16000 Hz
Input Sensitivity: 150mV, Output Level: 150mV (9V max), Gain: ± 12dB
Frequency response: 10Hz to 50kHz
Signal to Noise Ratio: 105dB
Total harmonic distortion: 0.0035%
Power Requirements:
Canadian Model - 120VAC 60Hz
100-120VAC / 220-240VAC 50/60Hz
Power Consumpton 25 Watts.



Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Mentioned in - - Manufacturers Literature (Owners Manual)

Model page created by Franz Scharner. See "Data change" for further contributors.
