Luxorita 3041

Luxor Radio AB; Motala

  • Year
  • 1974
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 180299
    • alternative name: Luxorita - voir Luxor Radio AB Suède (Sweden)

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 1
  • Main principle
  • Superheterodyne (common); ZF/IF 10700 kHz
  • Wave bands
  • FM Broadcast Band Only
  • Power type and voltage
  • Batteries / addl. power jack / 6 x 1,5 / 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 1.2 W (max.)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Luxorita 3041 - Luxor Radio AB; Motala
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 280 x 140 x 70 mm / 11 x 5.5 x 2.8 inch
  • Notes
  • Luxor Kofferradio Luxorita 3041, UKW-Gerät mit AFC, Tonblende.
    Anschlüsse für Tonbandgerät und separates Netzanschlußgerät. Gehäuse in den Farben rot/weiß, grün/weiß oder schwarz.

    5 L-C Kreise und ein Keramik-Filter SFE 10.7MA

  • Net weight (2.2 lb = 1 kg)
  • 1.7 kg / 3 lb 11.9 oz (3.744 lb)
  • Source of data
  • -- Original prospect or advert
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Michael Seiffert. See "Data change" for further contributors.
