• Country
• France

• Manufacturer / Brand
• Magenta Electronic; Paris

• Year
• 1972 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 196710

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• D7-200GH

• Number of Transistors
• 28

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110/220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Oscilloscope RO773 - Magenta Electronic; Paris

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 120 x 210 x 250 mm / 4.7 x 8.3 x 9.8 inch

• Notes
• Amplificateur Horirontal : 50Hz à 500KHz à -3dB. Sensibilité : 50mV/div à 250mV/div. Impédance d'entrée : 100k ohms shuntée par 100pF. Base de temps : 1µs à 0.2s.

• Net weight (2.2 lb = 1 kg)
• 3.5 kg / 7 lb 11.3 oz (7.709 lb)

• Price in first year of sale
• 1,476.00 FF

• Literature/Schematics (1)
• Le Haut-Parleur

• Author
• Model page created by Jean Marchal. See "Data change" for further contributors.
