25 series Ch= V25-04AA

• Country
• United States of America (USA)

• Manufacturer / Brand
• Magnavox Co., Commercial Wireless and Development Co.; San Francisco, later Fort Waye, IN

• Year
• 1958 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 183385

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 19

• Valves / Tubes
• 6BN4 6CG8A 6AU6 6DT6 6AT6 6DG6GT 6BZ6 6BZ6 6CB6 12BY7A 6AU6 12AU7 6CM7 6SN7GTB 6DQ6 1B3GT 6AX4GT 5U4GB 21CBP4

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 25 series Ch= V25-04AA - Magnavox Co., Commercial

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• Magnavox Chassis V25-04AA is a 21" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with VHF tuner 700624 and picture tube 21CBP4.



• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 6-58, Set 402, Folder 2)

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Set 383 Folder 14-S dated 1-58)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
