• Year
  • 1958 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 177333

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 16
  • Valves / Tubes
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 110 - 120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Ch= V27-03AA - Magnavox Co., Commercial
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • Television Receiver Chassis, Picture tube: 17CNP4, Prefix "U" stands for factory equipped with continuous UHF tuner, tube quantity UHF: 16
    Tuning Range: TV - Channels 2 thru 13, 14 thru 84 UHF.
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
