• Year
  • 1959
  • Category
  • Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
  • Radiomuseum.org ID
  • 187955

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 20
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 110 - 120 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Ch= V30-09AA - Magnavox Co., Commercial
  • Shape
  • Chassis only or for «building in»
  • Notes
  • 21" b/w TV with US standard VHF Tuner Channels 2 thru 13. Some Chassis with Picture Tube 24AHP4.
    Available is a Remote Control 700742-1, 700781 or 700782.
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
