- Country
- United States of America (USA)
- Manufacturer / Brand
- Magnavox Co., Commercial Wireless and Development Co.; San Francisco, later Fort Waye, IN
- Year
- 1957 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 313593
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Powered by external power supply or a main unit.
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Ch= CR-743 - Magnavox Co., Commercial
- Shape
- Chassis only or for «building in»
- Notes
-
Magnavox chassis CR-743 is an externally powered AM tuner.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 369 Folder 11 dated 9-57)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
