FM-AM Power Transistor 2-FM-806 (Japan 704)

FM-AM Power Transistor 2-FM-806 ; Magnavox Co., (ID = 2189508) Radio FM-AM Power Transistor 2-FM-806 ; Magnavox Co., (ID = 2189506) Radio
FM-AM Power Transistor 2-FM-806 ; Magnavox Co., (ID = 2189507) Radio FM-AM Power Transistor 2-FM-806 ; Magnavox Co., (ID = 2189512) Radio
FM-AM Power Transistor 2-FM-806 ; Magnavox Co., (ID = 2189513) Radio FM-AM Power Transistor 2-FM-806 ; Magnavox Co., (ID = 2189509) Radio
FM-AM Power Transistor 2-FM-806 ; Magnavox Co., (ID = 2231246) Radio FM-AM Power Transistor 2-FM-806 ; Magnavox Co., (ID = 2189510) Radio
FM-AM Power Transistor 2-FM-806 ; Magnavox Co., (ID = 2189511) Radio FM-AM Power Transistor 2-FM-806 ; Magnavox Co., (ID = 564747) Radio
Use red slider bar for more.
FM-AM Power Transistor 2-FM-806 ; Magnavox Co., (ID = 2189508) Radio
Magnavox Co.,: FM-AM Power Transistor 2-FM-806 [Radio] ID = 2189508 1200x1600
Select picture or schematic to display from thumbnails on the right and click for download.
For model FM-AM Power Transistor 2-FM-806 (Japan 704), Magnavox Co., Commercial Wireless and Development Co.; San Francisco, later Fort Waye, IN:
Front view swiveled right

Country:  United States of America (USA)
Manufacturer / Brand:  Magnavox Co., Commercial Wireless and Development Co.; San Francisco, later Fort Waye, IN
Year: 1969 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8:
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 1 x 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: FM-AM Power Transistor 2-FM-806 - Magnavox Co., Commercial
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 4.5 x 2.75 x 1.5 inch / 114 x 70 x 38 mm
Notes

Magnavox 2-FM-806 FM-AM Power Transistor;
FM: 87 - 108 MHz, AM-MW: 540 - 1600 KHz, cycle scale, earphones jack.

The radio most likely was made by Sanyo and it looks similar to the Sanyo FM/AM 8F-801.

Made in Japan 704

Source of data -- Collector info (Sammler)

Model page created by a member from A. See "Data change" for further contributors.
