Regency Symphony 155B - CR-188A - AMP-101A - CR-189A - W-C 56

Magnavox Co., Commercial Wireless and Development Co.; San Francisco, later Fort Waye, IN

  • Year
  • 1947
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 223418

 Technical Specifications

  • Number of Tubes
  • 21
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Wave bands
  • Broadcast, Short Wave plus FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 117 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Regency Symphony 155B - CR-188A - AMP-101A - CR-189A - W-C 56 - Magnavox Co., Commercial
  • Shape
  • Console with Push Buttons.
  • Dimensions (WHD)
  • 34 x 38 x 19 inch / 864 x 965 x 483 mm
  • Notes
  • AM Tuner = CR-188A, Amp = AMP-101A, FM tuner = CR-189A, Changer= W-C 56. "New" FM band; SW band 5.0 to 18.0 MHz.
  • Price in first year of sale
  • 410.00 $
  • Author
  • Model page created by Larry Long. See "Data change" for further contributors.
