- Country
- United States of America (USA)
- Manufacturer / Brand
- Magnavox Co., Commercial Wireless and Development Co.; San Francisco, later Fort Waye, IN
- Year
- 1965 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 347216
- Number of Transistors
- 7
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.5 inch = 6.4 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Solid State 1R1506 - Magnavox Co., Commercial
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 9.75 x 4 x 4 inch / 248 x 102 x 102 mm
- Notes
-
Magnavox Solid State AM Radio Model 1R1506.
Cabinet Color Green, Power consumption 5 Watts.
Clock radio version is the Magnavox 1R1507.Made in Singapore
- Net weight (2.2 lb = 1 kg)
- 1.6 lb (1 lb 9.6 oz) / 0.726 kg
- Author
- Model page created by Jerry Elarton. See "Data change" for further contributors.
