Ch= V74-01-AA 74-Series
Magnavox Co., Commercial Wireless and Development Co.; San Francisco, later Fort Waye, IN
- Country
- United States of America (USA)
- Manufacturer / Brand
- Magnavox Co., Commercial Wireless and Development Co.; San Francisco, later Fort Waye, IN
- Year
- 1957 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 315615
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 16
- Valves / Tubes
- 4BQ7A 5U8 3BZ6 3BZ6 12BY7A 5AN8 5U8 3DT6 12L6GT 6CG7 6CM7 6CG7 12DQ6 or 12DQ6A 12AX4GTA 1B3GT 24YP4 or 21ATP4
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Material
- Metal case
- from Radiomuseum.org
- Model: Ch= V74-01-AA 74-Series - Magnavox Co., Commercial
- Shape
- Chassis only or for «building in»
- Notes
-
Magnavox Chassis V74-01AA is a 21 or 24" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with VHF tuner 700558-2 and picture tube 24YP4 or 21ATP4.
