For model 10FM891 Ch= 10C23E, Majestic Radio & Television Co.,(post 1932):
SAMS Photofact Volume 7 Folder 4913-8

Country:  United States of America (USA)
Manufacturer / Brand:  Majestic Radio & Television Co.,(post 1932)
Year: 1949 ?? perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: 6BA6 6BE6 6SG7 6SA7 6SG7 6SG7 6SH7 6S8GT 6V6 5Y3G
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Wave bands Broadcast, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker 2 Loudspeakers / Ø 11.75 inch = 29.8 cm
Power out
from Radiomuseum.org Model: 10FM891 Ch= 10C23E - Majestic Radio & Television Co
Material Wooden case
Shape Console with any shape - in general
Notes

The Majestic model 10FM891 with chassis 10C23E receives broadcast 530 - 1700 kHz, SW 9,5 - 15,5 MHz and FM 87,5 - 108,5 MHz. 10FM891 is an AC Operated Combination Phono-Radio, an AM-FM Superheterodyne Receiver with bult-in Loop Antenna

External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 20 covering 1950
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Volume 7 Set #65 Folder 4913-8 07/49)


All listed radios etc. from Majestic Radio & Television Co.,(post 1932)
Here you find 333 models, 166 with images and 273 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
