1BR50

1BR50 ; Majestic Radio & (ID = 742658) Radio
1BR50 ; Majestic Radio & (ID = 653028) Radio 1BR50 ; Majestic Radio & (ID = 653033) Radio
1BR50 ; Majestic Radio & (ID = 653030) Radio 1BR50 ; Majestic Radio & (ID = 653029) Radio
1BR50 ; Majestic Radio & (ID = 653031) Radio 1BR50 ; Majestic Radio & (ID = 653032) Radio
Use red slider bar for more.
1BR50 ; Majestic Radio & (ID = 653028) Radio
Majestic Radio &: 1BR50 [Radio] ID = 653028 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model 1BR50, Majestic Radio & Television Co.,(post 1932)

Country:  United States of America (USA)
Manufacturer / Brand:  Majestic Radio & Television Co.,(post 1932)
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 1A7GT 1N5GT 1H5GT 1T5GT 25Z6GT
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Line / Batteries (any type) / AC 110; Batt. 90 & 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 1BR50 - Majestic Radio & Television Co
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 330 x 250 x 155 mm / 13 x 9.8 x 6.1 inch
Notes In mains mode the dial scale is illuminated. Built in loop antenna.
External source of data Ernst Erb
Source of data Collector's Guide to Antique Radios 4. Edition
Circuit diagram reference Rider's Perpetual, Volume 14 = 1944 = before 1943
Mentioned in The Radio Collector's Directory and Price Guide 1921 - 1965
Literature/Schematics (1) Riders 14-1
