6 Transistor Radio

6 Transistor Radio ; Manitone brand; Hong (ID = 2238616) Radio 6 Transistor Radio ; Manitone brand; Hong (ID = 2238620) Radio
6 Transistor Radio ; Manitone brand; Hong (ID = 2238617) Radio 6 Transistor Radio ; Manitone brand; Hong (ID = 2238618) Radio
6 Transistor Radio ; Manitone brand; Hong (ID = 2238619) Radio 6 Transistor Radio ; Manitone brand; Hong (ID = 2238621) Radio
6 Transistor Radio ; Manitone brand; Hong (ID = 2238622) Radio
Use red slider bar for more.
6 Transistor Radio ; Manitone brand; Hong (ID = 2238616) Radio
Manitone brand; Hong: 6 Transistor Radio [Radio] ID = 2238616 705x1024
Select picture or schematic to display from thumbnails on the right and click for download.
For model 6 Transistor Radio, Manitone (brand); Hong Kong

Country:  Hong Kong
Manufacturer / Brand:  Manitone (brand); Hong Kong
Year: 1968 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6:
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 4 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 6LR61: 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.6 cm = 2.2 inch
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: 6 Transistor Radio - Manitone brand; Hong Kong
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 68 x 108 x 34 mm / 2.7 x 4.3 x 1.3 inch
Notes

AM Taschenempfänger,

Empfangsbereich:
MW: 535 - 1605kHz.

Zubehör: Kunststofftasche.

Net weight (2.2 lb = 1 kg) 0.182 kg / 0 lb 6.4 oz (0.401 lb)

Model page created by Holger Struthoff. See "Data change" for further contributors.
