1105; His Master's Voice (ID = 24371) Radio
Use red slider bar for more.
1105; His Master's Voice (ID = 24371) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: X65 KTW61 DH63 KT63 U50
Main principle Superheterodyne (common); ZF/IF 465 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 195-255 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 1105 - His Master's Voice Masters,
Material Wooden case
Shape Tablemodel with Push Buttons.
Notes

There is also a Belgian HMV 1105, but this model uses the same chassis as the Marconiphone 888. The cabinet is like the HMV 1107

Push button waveband changing.

External source of data E. Erb 3-907007-36-0
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.
