His Master's Voice: 1402 [Radio] ID = 1962544 1181x2100
Select picture or schematic to display from thumbnails on the right and click for download.
For model 1402, His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB:
My Collection

Country:  Great Britain (UK)
Manufacturer / Brand:  His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB
Year: 1938/1939 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: W21 HL21 HL2 KT2
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker
Power out
from Radiomuseum.org Model: 1402 - His Master's Voice Masters,
Notes

A model with this schematic was imported into Switzerland in numbers and therefore Thali (well known in Switzerland only) has drawn its own schematic as a copy of the manufacturer. Thali considered the model as Marconi Co. but at least the picture of a set which might be that export model shows a HMV plate. We are not sure if this photo belongs to this model page but accepted the change of manufacturer. Who knows more? You might use the contact form if you are not a member.

External source of data E. Erb 3-907007-36-0
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.
