For model 276 AC MW only, Marconi Co. (Marconiphone, Marconi's Wireless Telegraph Co. Ltd.), GB (not tubes - see also HMV His Master's Voice)

Country:  Great Britain (UK)
Manufacturer / Brand:  Marconi Co. (Marconiphone, Marconi's Wireless Telegraph Co. Ltd.), GB (not tubes - see also HMV His Master's Voice)
Year: 1933 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: MH4Cat VMS4B VMS4B MS4B_Catkin MH4Cat PX4 U12
Main principle Superhet with RF-stage; ZF/IF 120 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage 200-210 or 211-230 or 231-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 10 inch = 25.4 cm
Power out 3.5 W (unknown quality)
from Radiomuseum.org Model: 276 AC [MW only] - Marconi Co. Marconiphone,
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 470 x 480 x 320 mm / 18.5 x 18.9 x 12.6 inch
Notes

This model has a similar circuit to that of the Marconiphone 276 AC but covers only Medium Wave and does not have a waveband switch. It also has two Westector W6s, one is in the AGC circuit and the other the detector.

Net weight (2.2 lb = 1 kg) 22 kg / 48 lb 7.3 oz (48.458 lb)
