3 Valve Radio Receiver 435

3 Valve Radio Receiver 435; His Master's Voice (ID = 24655) Radio

3 Valve Radio Receiver 435; His Master's Voice (ID = 24656) Radio
3 Valve Radio Receiver 435; His Master's Voice (ID = 1954197) Radio 3 Valve Radio Receiver 435; His Master's Voice (ID = 1971660) Radio
3 Valve Radio Receiver 435; His Master's Voice (ID = 1971661) Radio 3 Valve Radio Receiver 435; His Master's Voice (ID = 1971662) Radio
3 Valve Radio Receiver 435; His Master's Voice (ID = 1971663) Radio 3 Valve Radio Receiver 435; His Master's Voice (ID = 1971664) Radio
3 Valve Radio Receiver 435; His Master's Voice (ID = 1971665) Radio 3 Valve Radio Receiver 435; His Master's Voice (ID = 1971666) Radio
3 Valve Radio Receiver 435; His Master's Voice (ID = 1971667) Radio 3 Valve Radio Receiver 435; His Master's Voice (ID = 1971668) Radio
Use red slider bar for more.
3 Valve Radio Receiver 435; His Master's Voice (ID = 1954197) Radio
His Master's Voice: 3 Valve Radio Receiver 435 [Radio] ID = 1954197 1024x880
Select picture or schematic to display from thumbnails on the right and click for download.
For model 3 Valve Radio Receiver 435, His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB:
Ebay UK item no. seller 201492333587 lighthousevalleycids

Country:  Great Britain (UK)
Manufacturer / Brand:  His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB
Year: 1931 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: MS4B MH4 MPT4 U10
Main principle TRF with regeneration
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 95-164; 190-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 3 Valve Radio Receiver 435 - His Master's Voice Masters,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 16.75 x 16 x 12.25 inch / 425 x 406 x 311 mm
External source of data E. Erb 3-907007-36-0
Source of data Radio! Radio!
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.
Documents regarding this model
  Article in Wireless World, December 23rd, 1931 340 KB
