• Country
• France

• Manufacturer / Brand
• Marconi (marque), Cie. Fse. du Gramophone; Paris

• Year
• 1937 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 122172

• Number of Tubes
• 5

• Valves / Tubes
• EK2 EF5 EBC3 EL3 EZ3

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz; 2 AF stage(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 90; 110; 130; 150; 220; 250 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 11B Ch= 5737B [Bois] - Marconi marque, Cie. Fse. du

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 380 x 440 x 250 mm / 15 x 17.3 x 9.8 inch

• Notes

• Même modèle que Marconi 11, mais caisse en bois au lieu de bakélite.

  Équivalent au Pathé 75.

• Net weight (2.2 lb = 1 kg)
• 11 kg / 24 lb 3.7 oz (24.229 lb)

• Literature/Schematics (1)
• -- Original prospect or advert

• Author
• Model page created by Laurent Farnieras. See "Data change" for further contributors.
