His Master's Voice: 656 [Radio] ID = 2614621 1400x829

Select picture or schematic to display from thumbnails on the right and click for download.

For model 656, His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB

Country:

Great Britain (UK)

Manufacturer / Brand:

His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB

Year: 1938/1939

Category: Broadcast Receiver - or past WW2 Tuner

Valves / Tubes

7: KTW63 X65 KTW63 DH63 TI65 or Y63 KT63 U50

Main principle	Superhet with RF-stage; ZF/IF 465 kHz
Wave bands	Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage	Alternating Current supply (AC) / 195-255 Volt
Loudspeaker	Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org	Model: 656 - His Master's Voice Masters,
Material	Wooden case
Shape	Tablemodel, low profile (big size).
Notes	HMV equivalent of the Marconiphone 858 table radio. See also the similar HMV 657 with motor driven auto-tuning.
Price in first year of sale	490.00 SFR
External source of data	E. Erb 3-907007-36-0
Circuit diagram reference	Die «Thali Schemasammlung» führt das Modell.
Literature/Schematics (1)	Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (396)

All listed radios etc. from His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB
Here you find 395 models, 283 with images and 237 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.

Collection of Uday Kalburgi (IND)

Collection of Urmas Tingas (EST)
