Marconiphone 4156

Marconiphone 4156; Marconi Co. (ID = 578616) Radio

Marconiphone 4156; Marconi Co. (ID = 578617) Radio

Marconiphone 4156; Marconi Co. (ID = 578618) Radio

Marconiphone 4156; Marconi Co. (ID = 578620) Radio
Marconiphone 4156; Marconi Co. (ID = 578614) Radio Marconiphone 4156; Marconi Co. (ID = 578615) Radio
Use red slider bar for more.
Marconiphone 4156; Marconi Co. (ID = 578614) Radio
Marconi Co.: Marconiphone 4156 [Radio] ID = 578614 900x675
Select picture or schematic to display from thumbnails on the right and click for download.
For model Marconiphone 4156, Marconi Co. (Marconiphone, Marconi's Wireless Telegraph Co. Ltd.), GB (not tubes - see also HMV His Master's Voice)

Country:  Great Britain (UK)
Manufacturer / Brand:  Marconi Co. (Marconiphone, Marconi's Wireless Telegraph Co. Ltd.), GB (not tubes - see also HMV His Master's Voice)
Year: 1969 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: BF160 BF160 BF195 BF194 BF194 BF195 2SD1569 BC152 AC176 AC153
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz; 3 AF stage(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.75 W (unknown quality)
from Radiomuseum.org Model: Marconiphone 4156 - Marconi Co. Marconiphone,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes

Portable AM/FM transistor radio. AFC on FM and permeability tuned input coil for reception via a car aerial when the 'CAR' switch is pressed down. Sockets for earphone, tape recorder and car aerial. Elliptical loudspeaker 6 x 4 inch.

Wavebands:

  • LW 1111 - 2027 metres (270 - 148 kHz)
  • MW 186 - 566 metres (1640 - 530 kHz)
  • SW 16.7 - 50 metres (18 - 6 MHz)
  • VHF 87 - 108 MHz

The same chassis is fitted to the HMV 2156HMV 2158 and Ferguson 3168 which are in different cabinets.



Mentioned in Marconi Transistor Radios (see Aldo Andreani's website).
Literature/Schematics (1) Antique Radio Magazine n.54, April 2003, page 56. Written in Italian and English.
Literature/Schematics (2) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1940 dated 26 June 1970)

Model page created by Aldo Andreani. See "Data change" for further contributors.
