Marconiphone T24DAB no HMV

Marconiphone T24DAB; Marconi Co. (ID = 18607) Radio

Marconiphone T24DAB; Marconi Co. (ID = 533767) Radio

Marconiphone T24DAB; Marconi Co. (ID = 533768) Radio

Marconiphone T24DAB; Marconi Co. (ID = 1017932) Radio

Marconiphone T24DAB; Marconi Co. (ID = 1017933) Radio

Marconiphone T24DAB; Marconi Co. (ID = 2425100) Radio

Marconiphone T24DAB; Marconi Co. (ID = 2425101) Radio

Marconiphone T24DAB; Marconi Co. (ID = 2425102) Radio

Marconiphone T24DAB; Marconi Co. (ID = 2425103) Radio

Marconiphone T24DAB; Marconi Co. (ID = 2425104) Radio
Marconiphone T24DAB; Marconi Co. (ID = 1183760) Radio Marconiphone T24DAB; Marconi Co. (ID = 1290613) Radio
Marconiphone T24DAB; Marconi Co. (ID = 1183752) Radio Marconiphone T24DAB; Marconi Co. (ID = 1290615) Radio
Marconiphone T24DAB; Marconi Co. (ID = 29920) Radio Marconiphone T24DAB; Marconi Co. (ID = 29921) Radio
Marconiphone T24DAB; Marconi Co. (ID = 29922) Radio Marconiphone T24DAB; Marconi Co. (ID = 29923) Radio
Marconiphone T24DAB; Marconi Co. (ID = 163415) Radio Marconiphone T24DAB; Marconi Co. (ID = 226283) Radio
Use red slider bar for more.
Marconiphone T24DAB; Marconi Co. (ID = 1183760) Radio
Marconi Co.: Marconiphone T24DAB [Radio] ID = 1183760 920x1071
Select picture or schematic to display from thumbnails on the right and click for download.
For model Marconiphone T24DAB no HMV, Marconi Co. (Marconiphone, Marconi's Wireless Telegraph Co. Ltd.), GB (not tubes - see also HMV His Master's Voice):
Note spike on lid ensures switch must be at 'off' to close lid.

Country:  Great Britain (UK)
Manufacturer / Brand:  Marconi Co. (Marconiphone, Marconi's Wireless Telegraph Co. Ltd.), GB (not tubes - see also HMV His Master's Voice)
Year: 1950–1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: X17 W17 ZD17 N18
Main principle Superheterodyne (common); ZF/IF 360 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Line / Batteries (any type) / 195-255 / 7.5 & 90 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Marconiphone T24DAB [no HMV] - Marconi Co. Marconiphone,
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Notes The Marconiphone T24DAB was released in August 1950 and it appeared in sales adverts in February 1951 and September 1951. Our schematics show an X17 as the first valve but there may be some later models with an X18. The original listing was also X17, W17, ZD17 and N18. The original retail price excluding purchase tax and batteries was £13 8s 6d. Line power is AC/DC, batteries are a B126 (Ever Ready 90V HT) and 5 x U2 (7.5V LT).
Price in first year of sale 14.00 £
External source of data E. Erb 3-907007-36-0
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1046)


All listed radios etc. from Marconi Co. (Marconiphone, Marconi's Wireless Telegraph Co. Ltd.), GB (not tubes - see also HMV His Master's Voice)
Here you find 487 models, 306 with images and 312 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
