AF Oscillator TF2102M 52102-025T

AF Oscillator TF2102M 52102-025T; Marconi Instruments, (ID = 2366473) Equipment AF Oscillator TF2102M 52102-025T; Marconi Instruments, (ID = 2366479) Equipment
AF Oscillator TF2102M 52102-025T; Marconi Instruments, (ID = 2366480) Equipment AF Oscillator TF2102M 52102-025T; Marconi Instruments, (ID = 2366481) Equipment
AF Oscillator TF2102M 52102-025T; Marconi Instruments, (ID = 2368366) Equipment AF Oscillator TF2102M 52102-025T; Marconi Instruments, (ID = 2368859) Equipment
AF Oscillator TF2102M 52102-025T; Marconi Instruments, (ID = 2368860) Equipment
Use red slider bar for more.
AF Oscillator TF2102M 52102-025T; Marconi Instruments, (ID = 2366473) Equipment
Marconi Instruments,: AF Oscillator TF2102M 52102-025T [Equipment] ID = 2366473 1337x1600
Select picture or schematic to display from thumbnails on the right and click for download.
For model AF Oscillator TF2102M 52102-025T, Marconi Instruments, Marconi-Ekco (MI, MEI):
General view

Country:  Worldwide
Manufacturer / Brand:  Marconi Instruments, Marconi-Ekco (MI, MEI)
Year: 1975 ? Category: Service- or Lab Equipment
schematic requested
Details
Power type and voltage Alternating Current supply (AC) / 105 - 260 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: AF Oscillator TF2102M 52102-025T - Marconi Instruments, Marconi-
Material Metal case
Dimensions (WHD) 150 x 200 x 270 inch / 3810 x 5080 x 6858 mm
Notes

General-purpose AF sinewave source covering 3Hz - 30kHz

Net weight (2.2 lb = 1 kg) 3.8 kg / 8 lb 5.9 oz (8.37 lb)
Mentioned in - - Manufacturers Literature

Model page created by Julian Hardstone. See "Data change" for further contributors.



All listed radios etc. from Marconi Instruments, Marconi-Ekco (MI, MEI)
Here you find 79 models, 64 with images and 30 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Marconi Instruments,: AF Oscillator TF2102M 52102-025T
Threads: 1 | Posts: 1
Hits: 138     Replies: 0
marconi-in: Model variations
Julian Hardstone
07.Mar.19
  1

The type nuber for my unit should be TF2102M1, as shown on my latest images. .Type TF2102M came later and added a mains switch and power indicator.

Documentation for 2102MI is dated 7-68, for 2102M is dated 5-82

My unit was made in 1976. I no longer require schematics for this model.
