- Country
- Belgium
- Manufacturer / Brand
- Marconiphone; Belgium
- Year
- 1939
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 276866
Bild aus Prospekt
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 100; 250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 108A - Marconiphone; Belgium
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 620 x 470 x 380 mm / 24.4 x 18.5 x 15 inch
- Notes
-
Wave bands:
- SW: 16-50 m
- MW: 185-570 m
- LW: 900-2000 m
Automatic tuning with 8 push buttons.
- Price in first year of sale
- 3,600.00 BEF
- Mentioned in
- -- Original prospect or advert
- Literature/Schematics (1)
- Manuel de la Radio 1940, van Cortenberghe (p. 68-69)
- Author
- Model page created by Gidi Verheijen. See "Data change" for further contributors.
- Other Models
-
Here you find 14 models, 14 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Marconiphone; Belgium
