Benytone Stereo Integrated Amplifier M-2600A

Marubeni Corp., Osaka

Data
Forum
Pictures
Collections

  • Year
  • 1979 ??
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 264648

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 110/220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 200 W (340 W max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Benytone Stereo Integrated Amplifier M-2600A - Marubeni Corp., Osaka
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 422 x 77.5 x 302 mm / 16.6 x 3.1 x 11.9 inch
  • Notes

  • Marubeni Stereo Integrated Amplifier Model Benytone M-2600A.
    Power output: 100 watts per channel into 4Ω (stereo)
    Peak Music Power 2x 170 Watts
    Frequency response: 50 - 20000Hz
    Total harmonic distortion: 0.15%
    Damping factor: 30
    Input sensitivity: 2.5mV (MM), 150mV (line)
    Signal to noise ratio: 77dB (MM), 87dB (line)
    Output: 150mV (line)
    Power Level Meter
    Inputs:
    Phono, Tuner, AUX, Tape Monitor
    Bass- & Treble Control
    Loudness
    Speaker load impedance: 4Ω to 16Ω
    Power Consumption 210 Watts


  • Net weight (2.2 lb = 1 kg)
  • 5.8 kg / 12 lb 12.4 oz (12.775 lb)
  • Mentioned in
  • - - Manufacturers Literature (Service Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
