One Tube Medium Band Receiver
Massey Radio Company; Winchester, VA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Massey Radio Company; Winchester, VA
- Year
- 1923 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 344798
- Number of Tubes
- 1
- Valves / Tubes
- UV200
- Main principle
- TRF without regeneration
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage and/or dry batteries / 6 & 22 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Wooden case
- from Radiomuseum.org
- Model: One Tube Medium Band Receiver - Massey Radio Company;
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 7 x 9.25 x 6 inch / 178 x 235 x 152 mm
- Notes
-
This set is a likely a rebranded set from The Radio Telephone Mfg. Co.
The R.T.M. Tuner covered the 150-650 meter wavelength range. The "B" battery was contained within the set and outlets for the "A" battery leads in the back of the cabinet.
This set was identical to the Q. T. Light Company Type 79 which was identical to the Radio Telephone Mfg. Co. RTM Tuner and Detector except for panel engraving.
The Q. T. Light Company either bought the assets of the Radio Telephone Mfg. Co. or were simply labeling them as their own brand. This Massey badged set was likely part of the effort to dispose of the Radio Telephone Mfg. Co. assets.
- Net weight (2.2 lb = 1 kg)
- 4.1 lb (4 lb 1.6 oz) / 1.861 kg
- Author
- Model page created by Dan Dames. See "Data change" for further contributors.
