Sandown D120

Sandown D120; Masteradio, London (ID = 1267013) Radio

Sandown D120; Masteradio, London (ID = 1267014) Radio

Sandown D120; Masteradio, London (ID = 545325) Radio

Sandown D120; Masteradio, London (ID = 545326) Radio
Sandown D120; Masteradio, London (ID = 793263) Radio Sandown D120; Masteradio, London (ID = 793264) Radio
Sandown D120; Masteradio, London (ID = 793265) Radio Sandown D120; Masteradio, London (ID = 1267283) Radio
Sandown D120; Masteradio, London (ID = 1267285) Radio Sandown D120; Masteradio, London (ID = 1267290) Radio
Sandown D120; Masteradio, London (ID = 1267296) Radio
Use red slider bar for more.
Sandown D120; Masteradio, London (ID = 793263) Radio
Masteradio, London: Sandown D120 [Radio] ID = 793263 933x618
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sandown D120, Masteradio, London:
Foto de colección particular

Country:  Great Britain (UK)
Manufacturer / Brand:  Masteradio, London
Year: 1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12K8GT 12K7GT 12Q7GT 35L6GT 35Z4GT
Main principle Superheterodyne (common); ZF/IF 465 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage AC/DC-set / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Sandown D120 - Masteradio, London
Material Bakelite case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 257 x 170 x 140 mm / 10.1 x 6.7 x 5.5 inch
Notes Same cabinets for D110 (1946). Price £8.11s.10d plus Tax.
Price in first year of sale 9.00 GBP
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Trader Sheet 943

Model page created by Peter Hoddow. See "Data change" for further contributors.
