Panasonic Stereo Radio Cassette Recorder RX-FS420

• Country
• Japan

• Manufacturer / Brand
• Panasonic, Matsushita, National ナショナル (also tubes); Osaka

• Year
• 1991 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 240294

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 459/10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 220 / UM1: 6 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Power out
• 10 W (20 W max.)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Panasonic Stereo Radio Cassette Recorder RX-FS420 - Panasonic, Matsushita,

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 460 x 148 x 151 mm / 18.1 x 5.8 x 5.9 inch

• Notes

• Panasonic RX-FS420 Stereo Radio Cassette Recorder with graphic equalizer, built-in microphone, headphone jack. XBS extra bass system.

  Different power supplys: 220 VAC in Europe, AC 240 VAC in the UK.

  Made in Singapore.

• Net weight (2.2 lb = 1 kg)
• 1.950 kg / 4 lb 4.7 oz (4.295 lb)

• Source of data
• - - Manufacturers Literature

• Author
• Model page created by Walter Fackler. See "Data change" for further contributors.

• Other Models

• Here you find 2987 models, 2764 with images and 621 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Panasonic, Matsushita, National ナショナル (also tubes); Osaka
