100 Watt Amplifier M-1003

100 Watt Amplifier M-1003; McGohan Inc., Don; (ID = 469824) Ampl/Mixer 100 Watt Amplifier M-1003; McGohan Inc., Don; (ID = 469825) Ampl/Mixer
100 Watt Amplifier M-1003; McGohan Inc., Don; (ID = 469826) Ampl/Mixer 100 Watt Amplifier M-1003; McGohan Inc., Don; (ID = 469827) Ampl/Mixer
100 Watt Amplifier M-1003; McGohan Inc., Don; (ID = 2637701) Ampl/Mixer 100 Watt Amplifier M-1003; McGohan Inc., Don; (ID = 2637702) Ampl/Mixer
Use red slider bar for more.
100 Watt Amplifier M-1003; McGohan Inc., Don; (ID = 469824) Ampl/Mixer
McGohan Inc., Don;: 100 Watt Amplifier M-1003 [Ampl/Mixer] ID = 469824 544x272
Select picture or schematic to display from thumbnails on the right and click for download.
For model 100 Watt Amplifier M-1003, McGohan Inc., Don; Chicago, Ill.:
aus ebay, Verkäufer giles202

Country:  United States of America (USA)
Manufacturer / Brand:  McGohan Inc., Don; Chicago, Ill.
Year: 1960 ?? Category: Audio Amplifier or -mixer
Valves / Tubes 6: 12AX7 12AX7 12AV6 12AT7 8417 8417
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker - This model requires external speaker(s).
Power out 100 W (unknown quality)
from Radiomuseum.org Model: 100 Watt Amplifier M-1003 - McGohan Inc., Don; Chicago,
Material Metal case
Shape Tablemodel, low profile (big size).
Notes PA amp, 3 inputs.
Net weight (2.2 lb = 1 kg) 0.8 kg / 1 lb 12.2 oz (1.762 lb)
Source of data -- Collector info (Sammler)
Literature/Schematics (1) -- Schematic

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
