• Year
  • 1946
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 205320

 Technical Specifications

  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Wave bands
  • Broadcast only (MW).
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 5C5-DW9 Combo - Meck, John, Industries, Inc.;
  • Shape
  • Tablemodel, Box - most often with Lid (NOT slant panel).
  • Dimensions (WHD)
  • 13 x 12 x 8 inch / 330 x 305 x 203 mm
  • Notes
  • This John Meck model 5C5-DW9 is shown in "Radio & Television Retailing" issue March 1946. It has a built in loop antenna. In April it is shown as 505-DW9 with exactly the same picture and there is added the same model in an other cabinet with built in record player, called Combo. Since in March there is quite a series with 5C5 we are pretty sure that 505 is a printing error. We put the 505 in brackets to the name so it can be found also this way.
  • Price in first year of sale
  • 49.80 $
  • Author
  • Model page created by Ernst Erb. See "Data change" for further contributors.
