MD3211A /16; Mediator; La Chaux- (ID = 1766758) Radio
Mediator; La Chaux-: MD3211A /16 [Radio] ID = 1766758 1400x738
Select picture or schematic to display from thumbnails on the right and click for download.
For model MD3211A /16, Mediator; La Chaux-de-Fonds

Country:  Switzerland
Manufacturer / Brand:  Mediator; La Chaux-de-Fonds
Year: 1964 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH81 EBF89 ECL86 EM87
Semiconductors (the count is only for transistors) 2:
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and FM or UHF.
Details Wired Wireless Receiver (RF!)
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 14 cm = 5.5 inch
Power out
from Radiomuseum.org Model: MD3211A /16 - Mediator; La Chaux-de-Fonds
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 450 x 220 x 145 mm / 17.7 x 8.7 x 5.7 inch
Notes

See also similar models Aristona SA3211A, Philips B3X51A/16, Hornyphon Attache W345A.

Made in Austria.

Model page created by Christian Schaufelberger. See "Data change" for further contributors.
