For model All Transistor MD8401 /16, Mediator; La Chaux-de-Fonds

Country:  Switzerland
Manufacturer / Brand:  Mediator; La Chaux-de-Fonds
Year: 1965 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 4: AC125 AC125 AC128 AC128 Selen
Main principle Audio-Amplification
Wave bands - without
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: All Transistor MD8401 /16 - Mediator; La Chaux-de-Fonds
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 310 x 110 x 270 mm / 12.2 x 4.3 x 10.6 inch
Notes

Geschwindigkeiten: 33 1/3, 45 Upm.
Verwendbare Tonköpfe: AG3306, AG3310, AG3224, AG3228

Net weight (2.2 lb = 1 kg) 3.1 kg / 6 lb 13.3 oz (6.828 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Ignacio Rodriguez-Rodriguez. See "Data change" for further contributors.
