• Country
• United States of America (USA)

• Manufacturer / Brand
• Meissner Mfg. Div., Maguire Industries, Inc. (IL)

• Year
• 1951

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 46979

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 19

• Valves / Tubes
• 6SK7 6SK7 6SK7 6SA7 6H6 6AG5 6AG5 6AG5 6AG5 6AG5 6C4 9001 9001 6AL5 6J5 6J5 6SN7GT 6L6 6L6 5Y3G 5V4G

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: 9-1093 FM-AM Tuner-Amplifier - Meissner Mfg. Div., Maguire

• Shape
• Chassis only or for «building in»

• Notes
• Plus 6U5 and 6G4 tubes.

• Price in first year of sale
• 254.00 $

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 18 = 1949 and before

• Literature/Schematics (1)
• 1951 Newark catalog Nº 51
