Digital Voltmeter V530

Digital Voltmeter V530; Meratronik SA; (ID = 2045331) Equipment Digital Voltmeter V530; Meratronik SA; (ID = 2045332) Equipment
Use red slider bar for more.
Digital Voltmeter V530; Meratronik SA; (ID = 2045331) Equipment
Meratronik SA;: Digital Voltmeter V530 [Equipment] ID = 2045331 1400x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Digital Voltmeter V530, Meratronik SA; Warszawa

Country:  Poland
Manufacturer / Brand:  Meratronik SA; Warszawa
Year: 1974 ? Category: Service- or Lab Equipment
Valves / Tubes 5: Z567M Z566M Z566M Z566M Z566M
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 120/220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Digital Voltmeter V530 - Meratronik SA; Warszawa
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 220 x 140 x 230 mm / 8.7 x 5.5 x 9.1 inch
Notes

Meratronik Digital Voltmeter V530 mit Nixie Anzeigeröhren.
Messbereiche: 0,1 / 1 / 10 / 100 und 1000 Volt.

Spezieller, runder, zweipoliger Netzanschluss.

Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)

Model page created by Uwe Friedl. See "Data change" for further contributors.
