Metriso 1000V

Metriso 1000V; Metrawatt, BBC Goerz (ID = 1563053) Equipment
Metriso 1000V; Metrawatt, BBC Goerz (ID = 1699649) Equipment Metriso 1000V; Metrawatt, BBC Goerz (ID = 1699650) Equipment
Metriso 1000V; Metrawatt, BBC Goerz (ID = 1699656) Equipment Metriso 1000V; Metrawatt, BBC Goerz (ID = 1699652) Equipment
Metriso 1000V; Metrawatt, BBC Goerz (ID = 1699654) Equipment Metriso 1000V; Metrawatt, BBC Goerz (ID = 1699659) Equipment
Metriso 1000V; Metrawatt, BBC Goerz (ID = 1699661) Equipment Metriso 1000V; Metrawatt, BBC Goerz (ID = 569121) Equipment
Metriso 1000V; Metrawatt, BBC Goerz (ID = 569123) Equipment Metriso 1000V; Metrawatt, BBC Goerz (ID = 569125) Equipment
Use red slider bar for more.
Metriso 1000V; Metrawatt, BBC Goerz (ID = 1699649) Equipment
Metrawatt, BBC Goerz: Metriso 1000V [Equipment] ID = 1699649 933x975
Select picture or schematic to display from thumbnails on the right and click for download.
For model Metriso 1000V, Metrawatt, BBC Goerz Metrawatt, ABB Metrawatt; Nürnberg

Country:  Germany
Manufacturer / Brand:  Metrawatt, BBC Goerz Metrawatt, ABB Metrawatt; Nürnberg
Year: 1975 ?? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 6: BC147 or. BC237 2N1711 MP1613 or. 2N1536 BC141
Wave bands - without
Details
Power type and voltage Dry Batteries / D: 6 x 1,5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Metriso 1000V - Metrawatt, BBC Goerz Metrawatt
Material Modern plastics (no Bakelite or Catalin)
Dimensions (WHD) 245 x 140 x 110 mm / 9.6 x 5.5 x 4.3 inch
Notes

Analoges, batteriebetriebenes Meßgerät gef. nach VDE 0413 Teil 1.
AC/DC Volt bis 1 kV; Isolation bis 400 MΩ, Durchgangsprüfer.

Prüfgerät und Isolationsmeßgerät für Spannungen 100, 250, 500 und 1000 V;
Messen des Isolationswiderstands von 0,02 ... 400 MΩ bei
Meßspannung Un von 100, 250; 500 oder 1000 V, U Leerlauf bis 1,3 kV.
Lampe in der Prüfspitze dient neben der Beleuchtung einer Gut/Schlecht Beurteilung.

Jeder Transistortyp nur 1x gelistet.

Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Source of data -- Original-techn. papers.

Model page created by a member from D. See "Data change" for further contributors.
