For model Terrafix III JT & JT-H, Metrawatt, BBC Goerz Metrawatt, ABB Metrawatt; Nürnberg:
Es fehlt der Tragriemen

Country:  Germany
Manufacturer / Brand:  Metrawatt, BBC Goerz Metrawatt, ABB Metrawatt; Nürnberg
Year: 1960 ? Category: Service- or Lab Equipment
Wave bands - without
Details
Power type and voltage Solar- and/or muscle driven, also addl. power jack possible
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Terrafix III JT & JT-H - Metrawatt, BBC Goerz Metrawatt
Material Special material, described in the notes.
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 195 x 85 x 145 mm / 7.7 x 3.3 x 5.7 inch
Notes Erdungsmessgerät für Starkstrom-, Fernmelde- und Blitzschutzanlagen, mit 3 Klemmen zur direkten Messung von Erdungs- und Ohmschen Widerständen.
Gehäuse aus Metall (schwarzer Kräusellack), Oberteil aus Bakelit.
Annähernd logarithmisch geteilte Skala mit 70mm Länge zur direkten Ablesung des Erdungswiderstandes (kleinster ablesbarer Widerstand 0,07 Ω).
5 Messbereiche: 0-2 Ω, 0-10 Ω, 0-100 Ω, 0-1.000 Ω, 0-10.000 Ω
Erzeugung der Prüfspannung durch schleifringlosen Kurbelinduktor mit Fliehkraftregler.
Ausführung mit brauner Leder-Bereitschaftstasche (JT),
Ausführung im Eichenholz-Tragekasten (JT-H).
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Price in first year of sale 305.00 DM
External source of data ARLT Katalog 1960

Model page created by Harald Schlosser. See "Data change" for further contributors.
