• Country
• United States of America (USA)

• Manufacturer / Brand
• MFJ Enterprises; Starkville (MS)

• Year
• 1985 ??

• Category
• Amateur Equipment (Other, but not Key)

• Radiomuseum.org ID
• 277614

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 1

• Semiconductors
• 2N3904 1N34A 1N4006

• Main principle
• RF-Circuit or wave trap (separate, can also be an antenna with amp.)

• Wave bands
• Short Wave (SW only)

• Power type and voltage
• Batteries / addl. power jack / 1 x 9 (6LR61) / 12 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Deluxe Versa Tuner II MFJ-969 - MFJ Enterprises; Starkville MS

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 9.5 x 3.5 x 10.5 inch / 241 x 89 x 267 mm

• Notes

• Antenna Tuner; max. 300 W; roller inductor with counter.

• Author
• Model page created by Gottfried Silberhorn. See "Data change" for further contributors.

• Other Models

• Here you find 67 models, 65 with images and 41 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
