For model Stereo-Radio-Clock SRC3001, Mikroelektronik 'Anna Seghers', Neuhaus a.R, VEB, RFT; (Ostd.) - vorm. Röhrenwerk:
Messemuster 1989

Country:  Germany
Manufacturer / Brand:  Mikroelektronik 'Anna Seghers', Neuhaus a.R, VEB, RFT; (Ostd.) - vorm. Röhrenwerk
Year: 1989/1990 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
schematic requested
Main principle Superheterodyne (common)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 6 x 1,5 & 1,5 Volt
Loudspeaker 2 Loudspeakers
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Stereo-Radio-Clock SRC3001 - Mikroelektronik 'Anna Seghers'
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Clock ((Alarm-) Clock Radio).
Dimensions (WHD) 440 x 120 x 90 mm / 17.3 x 4.7 x 3.5 inch
Notes Das Uhrenradio SRC3001 wurde kurz vor der Auflösung der DDR entwickelt und lediglich in einer Nullserie produziert.
2 Endstufen à 2,5 Watt, Lautsprecherboxen abnehmbar.
Empfangsbereich KW: 49m-Band.
Externe Stromversorgung 12 V DC über zugehöriges Netzgerät SNT3000 (Hersteller: VEB Messtechnik Mellenbach, Betrieb des Kombinates VEB EAW).
Net weight (2.2 lb = 1 kg) 2.4 kg / 5 lb 4.6 oz (5.286 lb)
Source of data -- Collector info (Sammler)
Mentioned in (DDR) Funkamateur FA 12/1989 Streiflichter zur Leipziger Herbstmesse 1989

Model page created by Bernhard Nagel. See "Data change" for further contributors.
