Emetteur-Recepteur TR-PP-11
MILITARY France, production militaire commune
- Country
- France
- Manufacturer / Brand
- MILITARY France, production militaire commune
- Year
- 1966
- Category
- Military Transceiver (TRX)
- Radiomuseum.org ID
- 241236
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Transceiver; ZF/IF 11500 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Storage and/or dry batteries / 15 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Emetteur-Recepteur TR-PP-11 - MILITARY France, production
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 70 x 310 x 140 mm / 2.8 x 12.2 x 5.5 inch
- Notes
-
Handfunksprechgerät des französischen Militärs. Frequenzbereich 47,0 - 56,95 MHz, 6 Kanäle (Steckquarze) im 50 kHz-Raster, Frequenzmodulation, 0,5 W Sendeleistung. Betrieb mit Batterie PS-28.
- Net weight (2.2 lb = 1 kg)
- 1.7 kg / 3 lb 11.9 oz (3.744 lb)
- Author
- Model page created by Siegfried Droese. See "Data change" for further contributors.
