Service Buzzer Model 1914

Service Buzzer Model 1914; MILITARY U.S. (ID = 1509430) Military

Service Buzzer Model 1914; MILITARY U.S. (ID = 1509433) Military
Service Buzzer Model 1914; MILITARY U.S. (ID = 2257917) Military Service Buzzer Model 1914; MILITARY U.S. (ID = 1509458) Military
Service Buzzer Model 1914; MILITARY U.S. (ID = 1509460) Military Service Buzzer Model 1914; MILITARY U.S. (ID = 1509463) Military
Service Buzzer Model 1914; MILITARY U.S. (ID = 1509467) Military Service Buzzer Model 1914; MILITARY U.S. (ID = 1509468) Military
Service Buzzer Model 1914; MILITARY U.S. (ID = 1509469) Military
Use red slider bar for more.
Service Buzzer Model 1914; MILITARY U.S. (ID = 2257917) Military
MILITARY U.S.: Service Buzzer Model 1914 [Military] ID = 2257917 1400x1457
Select picture or schematic to display from thumbnails on the right and click for download.
For model Service Buzzer Model 1914, MILITARY U.S. (different makers for same model):
Collection privée (réf.: 1206)

Country:  United States of America (USA)
Manufacturer / Brand:  MILITARY U.S. (different makers for same model)
Year: 1914 ? Category: Military Equipment (not Re, Tr or RXT)
Wave bands - without
Details
Power type and voltage Dry Batteries / 4 x 1.5 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Service Buzzer Model 1914 - MILITARY U.S. different makers
Material Leather / canvas / plastic - over other material
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 190 x 90 x 135 mm / 7.5 x 3.5 x 5.3 inch
Notes

US Signal Corps Service Buzzer Model 1914. Portable device for field telephone line testing, can be operated as a buzzer or telephone.

Known manufacturers:
American Electric Co., Chicago, Order 4999, Sept. 5 1916
Stromberg-Carlson Tel. Mfg. Co., Rochester N.Y., Order No. 140245, Year 1918

Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)

Model page created by Rudolf Müller. See "Data change" for further contributors.
