Allwellen-Empfänger MR-73B
Minix, Hannover: Allwellen-Empfänger MR-73B [Amateur-R] ID = 314030 933x448
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
Brand
|
Richter & Co; Hannover | ||||
|---|---|---|---|---|---|
| Year: 1974–1978 ?? | Category: Amateur-Receiver (amateur bands, may include broadcast bands) | ||||
| Semiconductors (the count is only for transistors) | 11: 2SK19 2SK19 2SK19 2SC372 2SC372 2SC372 2SC372 2SC372 2SC735 2SC735 2SC372 2SC372 2SC710 µPC20 |
| Main principle | Superhet with RF-stage; ZF/IF 455 kHz |
|---|---|
| Wave bands | Broadcast plus more than 2 Short Wave bands. |
| Details | |
| Power type and voltage | Line plus power jack, mostly with battery or storage battery / 110; 220 / 12 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) |
| Power out | |
| from Radiomuseum.org | Model: Allwellen-Empfänger MR-73B - Minix, Hannover |
| Material | Metal case |
| Shape | Tablemodel, with any shape - general. |
| Dimensions (WHD) | 360 x 160 x 220 mm / 14.2 x 6.3 x 8.7 inch |
| Notes | Minix "Allwellenempfänger" MR-73B. Frequenzbereich 550 kHz bis 30,0 MHz in vier Bereichen, Bandspreizung für Amateurbänder. Betriebsarten: AM, CW/SSB mit BFO; keramisches ZF-Filter; Störbegrenzer. Betrieb mit externer 12-V-Gleichspannungsquelle möglich. Entwicklung und Vertrieb durch Richter & Co. in Hannover, hergestellt in Japan. In UK sold as SMC73 by South Midlands Communication Ltd., Southhampton. |
| Net weight (2.2 lb = 1 kg) | 6.5 kg / 14 lb 5.1 oz (14.317 lb) |
| Price in first year of sale | 515.00 DM |
| External source of data | Katalog Firma Richter, Hannover (RiCofunk) |
| Source of data | Radiokatalog Band 2, Ernst Erb |
Model page created by Werner Raacke. See "Data change" for further contributors.
