Belarus' {Беларусь} ; Minsk Radio Works; (ID = 136192) Television
Minsk Radio Works;: Belarus' {Беларусь} [Television] ID = 136192 280x229
Select picture or schematic to display from thumbnails on the right and click for download.
For model Belarus' {Беларусь}, Minsk Radio Works; Minsk:
Courtesy of V.Charcenko ..rw6ase.narod.ru

Country:  Soviet Union
Manufacturer / Brand:  Minsk Radio Works; Minsk
alternative name

Industrial Union Horizont || Minsk Works "Kalibr"
Year: 1954 Category: Television Receiver (TV) or Monitor
Valves / Tubes 20: 6Ж3П 6Н1П 6Ж3П 6Ж4П 6Ж3П 6П9 6Ж3П 6Ж3П 6Ж3П 6Ж8 6П6С 6Н1П 6П1П 6Н1П Г-807 31ЛК2Б 1Ц1С 6Ц4П 5Ц4С 5Ц4С
Semiconductors (the count is only for transistors) ДГ-Ц12 ДГ-Ц14 ДГ-Ц13 ДГ-Ц13
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: Belarus' {Беларусь} - Minsk Radio Works; Minsk
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 440 x 435 x 545 mm / 17.3 x 17.1 x 21.5 inch
Notes Picture tube 31LK2B; screen area 240 × 180 mm; Tuner sensibility 800 µV; Resolution 450 lines; Power Consumption 220 Watt.
Bildröhre 31LK2B; Bildgröße 240 × 180 mm; Tunerempfindlichkeit 800 µV; Auflösung 450 Linien; Leistungsaufnahme 220 Watt.
Net weight (2.2 lb = 1 kg) 35 kg / 77 lb 1.5 oz (77.093 lb)
Source of data -- Collector info (Sammler)

Model page created by a member from A. See "Data change" for further contributors.
