2 Band MW/SW Radio 8X-870

2 Band MW/SW Radio 8X-870; Mitsubishi Electric (ID = 1452918) Radio 2 Band MW/SW Radio 8X-870; Mitsubishi Electric (ID = 1452923) Radio
2 Band MW/SW Radio 8X-870; Mitsubishi Electric (ID = 1452924) Radio 2 Band MW/SW Radio 8X-870; Mitsubishi Electric (ID = 1452934) Radio
2 Band MW/SW Radio 8X-870; Mitsubishi Electric (ID = 1452935) Radio 2 Band MW/SW Radio 8X-870; Mitsubishi Electric (ID = 1454039) Radio
2 Band MW/SW Radio 8X-870; Mitsubishi Electric (ID = 1454040) Radio 2 Band MW/SW Radio 8X-870; Mitsubishi Electric (ID = 1454042) Radio
2 Band MW/SW Radio 8X-870; Mitsubishi Electric (ID = 1454045) Radio 2 Band MW/SW Radio 8X-870; Mitsubishi Electric (ID = 1454046) Radio
Use red slider bar for more.
2 Band MW/SW Radio 8X-870; Mitsubishi Electric (ID = 1452918) Radio
Mitsubishi Electric: 2 Band MW/SW Radio 8X-870 [Radio] ID = 1452918 930x729
Select picture or schematic to display from thumbnails on the right and click for download.
For model 2 Band MW/SW Radio 8X-870, Mitsubishi Electric Corporation

Country:  Japan
Manufacturer / Brand:  Mitsubishi Electric Corporation
Year: 1965 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: 2SC710 2SC710 2SC711 2SC711 2SB135 2SB135 unknown_tr unknown_tr
Main principle Superheterodyne (common)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Line / Batteries (any type) / 110; 220 / 3 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
Power out 0.3 W (max.)
from Radiomuseum.org Model: 2 Band MW/SW Radio 8X-870 - Mitsubishi Electric
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 210 x 120 x 65 mm / 8.3 x 4.7 x 2.6 inch

Model page created by Daniel Rosha. See "Data change" for further contributors.



All listed radios etc. from Mitsubishi Electric Corporation
Here you find 297 models, 235 with images and 88 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
