• Country
• Japan

• Manufacturer / Brand
• Mitsubishi Electric Corporation

• Year
• 1980 ?

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 211800

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 220/240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 60 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Integrated Amplifier DA-U210 - Mitsubishi Electric

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 425 x 139 x 324 mm / 16.7 x 5.5 x 12.8 inch

• Notes
• HiFi-Vollverstärker. Sinus 2x 30W an 4 Ohm (0,5% THD), 2 Powermeter 0,01-100W, regelbarer Mikrophoneingang, Phono MM-Eingang.

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
