Digital LCD Multimeter DMT-4000

Digital LCD Multimeter DMT-4000; Monacor, Bremen (ID = 1204652) Equipment

Digital LCD Multimeter DMT-4000; Monacor, Bremen (ID = 1204653) Equipment

Digital LCD Multimeter DMT-4000; Monacor, Bremen (ID = 1204655) Equipment

Digital LCD Multimeter DMT-4000; Monacor, Bremen (ID = 1204657) Equipment

Digital LCD Multimeter DMT-4000; Monacor, Bremen (ID = 1204660) Equipment
Digital LCD Multimeter DMT-4000; Monacor, Bremen (ID = 488435) Equipment Digital LCD Multimeter DMT-4000; Monacor, Bremen (ID = 488433) Equipment
Digital LCD Multimeter DMT-4000; Monacor, Bremen (ID = 488432) Equipment Digital LCD Multimeter DMT-4000; Monacor, Bremen (ID = 488437) Equipment
Digital LCD Multimeter DMT-4000; Monacor, Bremen (ID = 489445) Equipment Digital LCD Multimeter DMT-4000; Monacor, Bremen (ID = 1897522) Equipment
Use red slider bar for more.
Digital LCD Multimeter DMT-4000; Monacor, Bremen (ID = 488435) Equipment
Monacor, Bremen: Digital LCD Multimeter DMT-4000 [Equipment] ID = 488435 730x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Digital LCD Multimeter DMT-4000, Monacor, Bremen:
Sammlung

Country:  Germany
Manufacturer / Brand:  Monacor, Bremen
Year: 1992 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 2:
Wave bands - without
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Digital LCD Multimeter DMT-4000 - Monacor, Bremen
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 85 x 38 x 180 mm / 3.3 x 1.5 x 7.1 inch
Notes Digital LCD Multimeter DTM-4000,
Anzeige: 3-1/2-stellig LCD,
Messbereiche:
DCV: 0,2...1000 V, ACV: 0,2...750 V,
DCA, ACA: 0,2...200 mA und 20 A,
Widerstand: 0...20 MOhm,
Eingangswiderstand 10 MOhm an allen DC/AC Spannungsbereichen, Polaritätswahl automatisch, Nullpunkt automatisch, Transistortestbuchsen für NPN und PNP, Battrieanzeige, 9 V Blockbatterie.
Net weight (2.2 lb = 1 kg) 0.3 kg / 0 lb 10.6 oz (0.661 lb)
Price in first year of sale 36.00 DM

Model page created by Karlheinz Fischer. See "Data change" for further contributors.
