• Country
• Germany

• Manufacturer / Brand
• Monacor, Bremen

• Year
• 1990 ??

• Category
• Miscellaneous (Other, Various) - see notes

• Radiomuseum.org ID
• 253590

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Professional Digital Delay - Digital-Echogerät EEM-3000 - Monacor, Bremen

• Shape
• Rack

• Dimensions (WHD)
• 482 x 44 x 193 mm / 19 x 1.7 x 7.6 inch

• Notes

• Digital-Echogerät EEM-3000 zum Rack-Einbau.
  Verzögerungszeit 2-1024 mSec.

• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
